Product Number:GM500

Product Usage:Customizing a screw machine to specific product requirements involves tailoring the machine’s features and settings to meet the precise needs of the product being manufactured.

Applicable Industries:Suitable for automatic screw locking operations such as small home appliances, electronic products, communications, mobile phones, tablets, laptops, keyboards, etc.

National Advisory Hotline

National Advisory Hotline:

+86 18975335491
  • Product Details

GM500 Automated Screw Assembly Machine

     The GM500 Automated Screw Assembly Machine from JHIMS delivers precision screw driving and efficiency for industries like electronics, appliances, and automotive. Built with trusted Japan HIOS and OMRON components, it offers customizable solutions starting at $1700 for standard models. Contact us for a custom quote today!

GM500 Automated Screw Assembly Machine for industrial applications

1. Benefits of the GM500

  • Boosts assembly line efficiency with automated screw assembly
  • Ensures precision screw driving and reduces errors
  • Fully customizable for non-standard industrial applications

2. Features

  • Continuous feeding with screw counting and anti-leakage functions
  • Direct screw transport to batch nozzle, saving time
  • Ideal for electric kettles, air fresheners, hair dryers, air conditioners, washing machines, mechanical watches, industrial power supplies, motors, circuit boards, automotive electronics, TV set-top boxes, toys, mobile phones, and more

3. Specifications

Specification Details
Model GM500
Electric Batch System Japan HIOS
Programming Method Teaching programming or graphics import
Control System SCM + handheld box control
Travel Range (X/Y/Z) 500/500/100 mm (customizable)
Maximum Load 10 kg
Movement Speed 0-800 mm/s
Time to Lock a Screw 0.6-1.5 seconds
Repeat Accuracy ±0.02 mm/axis
Program Record Mode 999 groups
Display Mode LCD teaching box
Guide Taiwan Shangyin Linear Guide
8000P Electric Batch Torque (optional) N·m: 0.39-1.76, Lbf·in: 3.52-15.84, Kgf·cm: 4-18
Sensor OMRON
Screw Arrangement Machine Capacity Screw (M2*6): 5000 pcs (varies by size)
Motor System (Z axis) Servo closed loop motor
Motor System (X/Y axis) Japan micro stepping precision motor
Transmission Mode (Z axis) Taiwan Shangyin Screw (optional)
Transmission Mode (X/Y axis) Italy Elate timing belt
Drive Lei Sai
Alarm Function Floating lock, sliding teeth, leaking lock
Applicable Screws M0.9-M6.0
Input Power Full voltage AC110V-220V
External Control Interface RS232

4. Applications

Perfect for electric drill lock screw machines, LED panel light lock screws, hexagon socket lock screw machines, notebook lock screw machines, square gasket lock screw machines, and double-head blown automatic lock screw machines. All products support non-standard customization.

5. Why Choose JHIMS?

  • Trusted components from Japan HIOS and OMRON for reliability
  • Expertise in industrial automation solutions
  • Customizable designs to meet unique production needs

6. Customer Testimonials

"The GM500 transformed our assembly line with its speed and precision." - Electronics Manufacturer

"JHIMS provided excellent customization support for our specific needs." - Automotive Supplier

Note: Replace with actual testimonials if available.

7. Case Study: Automotive Electronics Success

A leading automotive electronics manufacturer reduced assembly time by 30% using the GM500’s precision screw driving and custom configuration. Contact us to see how it can work for you!

8. Watch the GM500 in Action

Video coming soon! Check back for a demonstration of the GM500’s automated screw assembly capabilities.

9. Frequently Asked Questions

What industries can use the GM500?

Electronics, appliances, automotive, and more.

How does the GM500 improve efficiency?

Automated screw locking reduces errors and speeds up production.

Can the GM500 be customized?

Yes, it supports non-standard customization for unique production needs.

10. Related Products

For more details or a custom quote, contact us today!
